| Performance Specification | Electrical Specification | Structure specification | ||
| Display size | Input range | PCB | ||
| 10.1" TFT | DC10.8V～DC28V,built-in isolated power supply | Built-in | ||
| Display area | Power | Shell material | ||
| 222.72mm(W)x125.28mm(H) | 7W@DC24V | Metal | ||
| Resolution | Allowable loss of power | Shape size | ||
| 1024*600 px | <3ms | 271*213*38mm | ||
| Display color | Insulation resistance | Cutout size | ||
| 16.77M | Over 50MΩ@500V DC | 260*202mm | ||
| Visual angle | Hi-pot test | Installation mode | ||
| 70/70/60/60(L/R/U/D) | 500V AC 1 minute | Installation of Fasteners and VESA Mounting(VESA100*100mm) | ||
| Contrast | Weight | |||
| 500:01:00 | Environmental Specification | 1.1KG | ||
| Backlight | Working temperature | |||
| LED | 0~50℃ | Product Certification | ||
| Luminance | Working humidity | Panel protection grade | ||
| 350cd/m² | 10~90%RH (non-condensing) | Conforming to IP65 certification (4208-93) | ||
| LCD life | Storage temperature | CE certification | ||
| ＞30000 hours | -20~60℃ | EN IEC61000-6-4:2019，EN IEC61000-6-2:2019 | ||
| Touch panel | Storage humidity | |||
| 4 line precision resistance network | 10~90%RH (non-condensing) | |||
| CPU | Sine vibration test | |||
| Quad-core 1.8GHz | 10~500Hz, 30m/s², X,Y,Z direction/hour | |||
| Memory | Cooling mode | |||
| 8GB Flash Memory+1GB Memory | Natural air cooling | |||
| RTC | ||||
| Built-in(512KB) | ||||
| External storage | ||||
| 1 USB Host | ||||
| Printer port | ||||
| USB Host/Serial port | ||||
| Ethernet | ||||
| LAN0:10/100/1000 Mbps;LAN1:10/100 Mbps | ||||
| Program download | ||||
| Ethernet port/USB Slave/U disk | ||||
| Communication | ||||
| COM0:RS232/RS485/RS422;COM2:RS232; |
10.1" , 16 milliontruecolors;
Dual Ethernet and serial ports for reliable communication;
High-performance quad-core processor, 1GB RAM memory and 8GB NAND flash;
Built-in isolated power supply and triple-proof coating,Prevent external interference and enhance product reliability;
Smooth and natural lines, overall simple and stylish design;
