15 inches, 1024*768 resolution, 16 million true colors
88/88/88/88 near full viewing angle display
Quad-core CPU + 512MB memory + 4G storage
Dual network ports + three serial ports, support dual RS485 applications
Built-in isolated power supply, good protection
Equipped with the latest Kinco DToolsPro configuration software
| Performance Specification | Electrical Specification | Environmental Specification | ||
| Display size | Input range | Working temperature | ||
| 15" TFT | DC18V～DC28V,built-in isolated power supply | 0~50℃ | ||
| Display area | Power | Working humidity | ||
| 344.16mm(W)x193.59mm(H) | 15W@DC24V | 10~90%RH (non-condensing) | ||
| Resolution | Allowable loss of power | Storage temperature | ||
| 1920*1080px | <3ms | -20~60℃ | ||
| Display color | Insulation resistance | Storage humidity | ||
| 16.7M | Over 50MΩ@500V DC | 10~90%RH (non-condensing) | ||
| Visual angle | Hi-pot test | Sine vibration test | ||
| 80/80/80/80(L/R/U/D) | 500V AC 1 minute | 10~500Hz, 30m/s², X,Y,Z direction/hour | ||
| Contrast | Cooling mode | |||
| 1000:01:00 | Structure specification | Natural air cooling | ||
| Backlight | PCB | |||
| LED | None | Product Certification | ||
| Luminance | Shell material | Panel protection grade | ||
| 250cd/m² | Metal | Conforming to IP65 certification (4208-93) | ||
| LCD life | Shape size | CE certification | ||
| ＞20000 hours | 395*259*25.5mm | EN IEC61000-6-4:2019，EN IEC61000-6-2:2019 | ||
| Touch panel | Cutout size | |||
| 4 line precision resistance network（surface hardness 3H） | 381.5*245.5mm | Software | ||
| CPU | Installation mode | Configuration software | ||
| Quad-core 1.5GHz | Installation of Fasteners and VESA Mounting(VESA100*100mm) | Kinco DToolsPro | ||
| Memory | Weight | |||
| 4GB Flash Memory+512MB Memory | 2.5KG | |||
| RTC | ||||
| Built-in | ||||
| External storage | ||||
| 1 USB Host | ||||
| Printer port | ||||
| USB Host/Serial port | ||||
| Ethernet | ||||
| LAN0:10/100 Mbps; LAN1:10/100 Mbps | ||||
| Program download | ||||
| Ethernet port/USB Slave/U disk | ||||
| Communication | ||||
| COM0:RS232/RS485/RS422;COM2:RS232; |
